Manual Push Lifting Beam Trolley With Safety Baffle Chain Block 0.5 Ton

Manual Push Lifting Beam Trolley With Safety Baffle Chain Block 0.5 Ton

Manual Push Lifting Beam Trolley With Safety Baffle Chain Block 0.5 Ton
Manual Push Lifting Beam Trolley With Safety Baffle Chain Block 0.5 Ton
Manual Push Lifting Beam Trolley With Safety Baffle Chain Block 0.5 Ton
Product Details:
Place of Origin: Chongqing, China
Brand Name: Shuangyan
Certification: ISO 9001, CE
Model Number: GCL B
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs mixed models
Packaging Details: carton box or wooden box
Delivery Time: 30 days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 20000 pieces/ month
Contact Now
Detailed Product Description
Company Type: Factory Customers' Type: Wholesalers, Distributers, Importers
Product Name: Manual Push Trolley With Safety Baffle For I-Beam With Lifting Chain Block Warranty: 1 Year
Color: Customizable Material: Steel
Application: Industrial Capacity: 0.5 Ton - 30 Ton
Price: EXW, FOB, CIF Keywords: I-beam Trolley, Manual Girder Trolley
High Light:

Manual Push Lifting Beam Trolley

,

Lifting Beam Trolley With Safety Baffle

,

Chain Block 0.5 Ton Lifting Beam Trolley

Manual Push Trolley with Safety Baffle for I-Beam with Lifting Chain Block

Type: GCT-A/GCT-B 0.5 ton-30 ton



Our Company's Type: Factory

Customers' Types: Importers, Distributers, Wholesalers



Products Description:



GCT/GCL series trolley ,running on the bottom flange of monorail, is hand-operated by pulling hand chain. Attached with chain hoist it can form a trolley type chain hoist which is used widely in factory, mines, engine room and other places for installing equipment as well as conveying goods, they are warehouse preferred where is no power.





Specification:





Model (GCL-B)     GCT0.5 GCT1 GCT2 GCT3 GCT5 GCT10 GCT20
Capacity   Ton 0.5 1 2 3 5 10 20
Test load   Ton 0.63 1.25 2.5 4 6.3 12.5 25
Min. radius of curve   m 1 1 1.3 1.5 1.6 2.2 5
I-beam recommended   mm 68-130 68-130 88-146 110-154 116-170 130-180 136-180
Dimensions A mm 200 220 230 242 276 330 460
B mm 163/200 186/223 218/258 248/296 286.6/344 400 810
C mm 173.5 205.5 232 282 327 423.5 438
H mm 111 131 143 176 204 239 242
Net weight   kg 6.3 8 13.4 22.1 32.6 67 150
Gross weight   kg 6.6 8.5 13.9 23.1 34.6 77 165






Products Details:



  1.  Color orange, red, gray, black ect.
  2.  0.5 ton - 20 ton capacity, contact us for other tonnage customization
  3.  Parts supply fully and rapidly
  4.  Surface treatment: painting, galvanized

Manual Push Lifting Beam Trolley With Safety Baffle Chain Block 0.5 Ton 0

Manual Push Lifting Beam Trolley With Safety Baffle Chain Block 0.5 Ton 1

Manual Push Lifting Beam Trolley With Safety Baffle Chain Block 0.5 Ton 2

Manual Push Lifting Beam Trolley With Safety Baffle Chain Block 0.5 Ton 3



Company profile:



The former Chongqing Chain Block factory, with more than 40 years history of manual hoist production, is now Chongqing Kinglong Machinery Co.,LTD, located in Chongqing, China. The company occupies an area of 27,000 square meters, among which the workshop has 14,000 square meters, staying on the road side with a distance of 3km from Chongqing West Railway Station and around 28km from Chonqging port. Both land and water transportation are convenient.



With experiences on producing manual hoists for more than 40 years, we have possessed perfect testing devices and the advanced equipment, including seven computer-controlled lines for high strength chains imported from Germany and Italy, and other automatic and semiautomatic digital controlled machines. Our main items are various models of chain blocks, lever blocks, trolley and high strength chains as well as chain assembly. As one of the biggest professional manufacturers of china blocks in China, our present production for chain blocks has reached 250,000 sets and high strength chains 1,250,000 meters in a year.



Our own brands "SHAN CHENG" "Shuangyan" for chain block, lever block and trolley are very popular in domestic and overseas because of their high quality.



The principle of Chongqing Kinglong Machinery Co.,LTD is dedicated to provide the first-class products and satisfactory services after sales.



Manual Push Lifting Beam Trolley With Safety Baffle Chain Block 0.5 Ton 4





Advantages:





  1.  Production Advantage---27,000 square meters, 250,000 sets chain block production ability, G80 chain 1,250,000 meters per year

  2.  Equipment Advantage---seven computer-controlled chains lines from Europe, two assembly line for chain block, over 100 machines   for parts and middle process treatment
  3.  Quality Advantage---ISO9001, our big customers test annually, CE certification, GS certification
  4.  Brand Advantage---"Shancheng" & "Shuangyan" very famouse in domestic for many years
  5.  Service Advantage---Product diversity, Customer satisfactory First, Quality No. 1, Service No. 1.
